The new T-106 lifting tower model TK6422 is a tower designed to lift vertical loads up to 225 Kg and 6.4 metres high. Composed of 5 extendable steel profiles raised by means of a high resistance steel cable. The tower section is fixed to the working height by means of an automatic steel safety pin. Legs with non-slip rubber feet. The whole system is operated by a manually operated winch.
| Material | Steel |
| Folded Height | 1,84 m / 6,03 ft |
| Extended base dimensions | 2,65 x 2,65 m/ 8,69 x 8,69 ft |
| Folded base dimensions | 0,46 x 0,46 m/ 1,51 x 1,51 ft |
| Maximum height | 6,4 m / 21 ft |
| Minimun height | 1,84 m / 6,03 ft |
| No. of sections | 5 |
| Minimum Load | 25 Kg / 55,12 lb |
| Max load (mechanism mode) | 225 Kg / 496,04 lb |
| Winch | 900 Kg / 1984,16 lb |
| Cable diameter | 6 mm / 0,24 in |
| Noise Emission | 75 dB |
| Compatible accessories | ATCMOS / ATCMOB / ATCLTS / ATC6FS / ATC29S / ATCBAS |
| Security systems | Self locking safety pins |
| Standards and Certifications | CE, DGUV, BGV C1, BGG 912 |
| Weight | 95 Kg / 209,44 lb |
| Unfolded base diameter | 2,555 m / 8,38 ft |
