SC-MAGELLAN SPK225 Speaker./sort

Høyttaler koaksialkabel.

Varenr: 425-0201

53,-eks. mva

Logg inn for å se dine nettopriser.
Ikke kunde? Søk om kundestatus.

Tverrsnitt2 x 2.5 mm²

Materiale

100+ på lager

Beskrivelse

Speaker Cable SC-Magellan SPK; 2 x 2,50 mm²; PVC Ø 6,00 mm; black

Teknisk info

Application	Speaker Cable
Application area	ELA 100 V Installation Studio / Broadcast
BPVo-Euroclass	Fca
Capac. cond./cond. per 1 m (audio)	150 pF
Colour	black
Colour detailed	black
Conductor resistance per 1 km	7,8 Ohm
Copper strand Ø (audio)	0,1 mm
Copper strands (audio)	322
Fire load per m	0,18 kWh
Height	6 mm
Inner conductor (audio)	2 2,5 mm²
Inner conductor Ø (audio)	1,78 mm
Insulation resist. per 1 km	0,2 G Ohm
Insulation resist. per 1 km (audio)	0,2 G Ohm
Jacket material	PVC
Jacket Ø	6 mm
Materiale	PVC
Number of Channels (audio)	1
Packing	100 m spool 500 m spool
Properties	Analog OFC oxygen free copper
Shield. resistance per 1 km	9 Ohm
Shielding	Double copper spiral, counter-rotating
Shielding factor	1
Style variant	round
Temperature max.	70 °C
Temperature min.	-25 °C
Tverrsnitt	2 x 2.5 mm²
Type	Høyttalerkabel
UV-resistant	Yes
Weight per 1 m	73 g
Width	6 mm
