SC-MONOCAT 110C CAT.7 + 3x2,5 sort,PVC

CAT og strøm hybrid

Varenr: 500-0151-1

189,-eks. mva

Logg inn for å se dine nettopriser.
Ikke kunde? Søk om kundestatus.

Kanaler1xCAT+POWER

Materiale

ikke på lager (14 dager)

Beskrivelse

SC-Monocat 110C; power: 3 x 2,50 mm²x CAT.7; PVC Ø 13,80 mm; black

Teknisk info

Application	hybrid cable
Application area	Installation Mobile outdoor / indoor Stage / live Studio / Broadcast
BPVo-Euroclass	Fca
Capacity wire/wire at 1m (network)	44 pF
Colour	black
Colour detailed	black
Conductor insulation material	Foam/Skin-PE
Fire load per m	0,77 kWh
Height	13,8 mm
Impedance (network)	100 Ohm
Inner conductor (network)	0,14 mm²
Inner conductor (power)	2,5 mm² 3
Insulation resist. per 1km (power)	5 G Ohm
Jacket material	PVC
Jacket Ø	13,8 mm
Kanaler	1xCAT+POWER
Materiale	PVC
Max. section length	100 m
Name	SC-Monocat 110C
Nominal voltage (power)	300 V
Operating voltage (power)	300 V
Packing	bulk stock
Properties	Analog Digital 110 Ohm AES / EBU OFC oxygen free copper
Shielding (network)	AL / PT-foil + Copper braiding tin-plated
Shielding factor	1
Style variant	round
Temperature max.	70 °C
Temperature min.	-20 °C
Type	AES/EBU DMX512
UV-resistant	Yes
Weight per 1 m	205 g
Width	13,8 mm
