Application
|
DMX
|
|
Application area
|
- ELA 100 V
- Installation
- Mobile outdoor / indoor
- Stage / live
- Studio / Broadcast
|
|
AWG (AES/EBU, DMX)
|
22
|
|
BPVo-Euroclass
|
Fca
|
|
Capac. cond./cond. per 1 m (AES/EBU, DMX)
|
58 pF
|
|
Capac. cond./shield. per 1 m (AES/EBU, DMX)
|
100 pF
|
|
Colour
|
black
|
|
Colour detailed
|
black
|
|
Conductor insulation material
|
PE
|
|
Conductor insulation Ø
|
1,7 mm
|
|
Conductor resistance per 1 km
|
53 Ohm
|
|
Copper strand Ø (AES/EBU, DMX)
|
0,25 mm
|
|
Copper strands (AES/EBU, DMX)
|
7
|
|
Farge
|
Sort
|
|
Fire load per m
|
0,22 kWh
|
|
Height
|
7 mm
|
|
Impedance
|
110 Ohm
|
|
Inner conductor (AES/EBU, DMX)
|
|
|
Inner conductor Ø (AES/EBU, DMX)
|
0,66 mm
|
|
Insulation resist. per 1 km
|
5 G Ohm
|
|
Insulation resist. per 1 km (AES/EBU, DMX)
|
5 G Ohm
|
|
Jacket material
|
PUR-Blend
|
|
Materiale
|
PUR-BLEND
|
|
Number of Channels (AES/EBU, DMX)
|
1
|
|
Packing
|
100 m spool
|
|
Properties
|
- Analog
- Digital 110 Ohm AES / EBU
- OFC oxygen free copper
- PUR Master Blend
|
|
Shield. resistance per 1 km
|
15 Ohm
|
|
Shielding
|
Copper-cross mesh, tined + AL / PT foil
|
|
Shielding factor
|
1
|
|
Signal transmission
|
symmetrical
|
|
Style variant
|
round
|
|
Temperature max.
|
70 °C
|
|
Temperature min.
|
-25 °C
|
|
Type
|
AES/EBU DMX512
|
|
UV-resistant
|
Yes
|
|
Weight per 1 m
|
65 g
|
|
Width
|
7 mm
|
